Storage Space Calculator
Discover how much you can increase your storage capacity. Compare counterbalanced forklifts, reach trucks, VNA, push-back, and autonomous 4D shuttle systems.
Save up to 80% of floor space with the right racking system.
Understanding Space Efficiency
How Aisle Width & Building Height Impact Storage
The key to maximizing warehouse storage is understanding the relationship between forklift type, aisle width, and building clear height. Narrower aisles and taller buildings dramatically increase pallet positions.
Aisle Width Comparison
Counterbalanced
Standard forklift - widest aisle requirement
Aisle Width Required
12ft
Aisle Width
20ft
Max Lift
Reach Truck
Extended reach forks - narrower aisles, higher stacking
Aisle Width Required
8.75ft
Aisle Width
40ft
Max Lift
VNA Swing-Reach
Very narrow aisle - works both sides simultaneously
Aisle Width Required
5.5ft
Aisle Width
55ft
Max Lift
Why Aisle Width Matters
In a typical warehouse, aisles consume 50-60% of floor space with counterbalanced forklifts. By switching to VNA equipment with 5.5ft aisles, you can add up to 50% more rack positions in the same building footprint. This is often more cost-effective than expanding or relocating to a larger facility.
Building Height Impact
4
Levels
21ft Clear
Existing/Older Building
5
Levels
27ft Clear
Spec Building
8
Levels
40ft Clear
Purpose Built
11
Levels
55ft Clear
High Rise
2.75x
More storage in 55ft vs 21ft building
74%
Space savings with VNA in high-rise
11
Storage levels possible at 55ft
Space Savings by System & Building Type
| Racking System | 21ft Building | 27ft Building | 40ft Building | 55ft Building |
|---|---|---|---|---|
| Counterbalanced (Baseline) | — | — | — | N/A |
| Reach Truck | 16% | 33% | 56% | N/A |
| VNA Swing-Reach | 32% | 45% | 69% | 74% |
| Double Deep Reach | 29% | 48% | 67% | N/A |
| 4D Shuttle System | 70% | 75% | 80% | 85%+ |
Facility Specifications
Estimated Storage Capacity
Total Square Footage
0 SF
Usable Space (85%)
0 SF
Total Pallet Positions
0
Rack Levels
0
Pallets/1000 SF
0
Want a detailed analysis for your specific requirements?
Get A Budget QuoteWhy Use the 4D Shuttle System?
Maximize your warehouse storage density with our advanced 4D shuttle solutions.
85% Storage Density
4D Shuttle systems achieve up to 85% storage density compared to 42% with selective racking.
Double Your Capacity
Store twice as many pallets in the same footprint by eliminating unnecessary aisles.
Flexible Configuration
Configure lanes of any depth to match your SKU profiles and throughput requirements.
